Pressure Transmitter

Discover the strength and durability of our Pressure Transmitter, expertly curated for industrial excellence by us, a leading supplier, trader, and wholesaler with over 2 years of experience in the sector. Explore our superb product range, including the TFPS70 Smart Pressure Transmitter, TFP40T Piezoresistive Pressure Transmitter, TFP40C Ceramic Pressure Transmitter, TFP300 Flush Diaphragm Pressure Transmitter, and TFP40S Piezoresistive Pressure Transmitter, each offering ultimate accuracy and stability. Our selection offers incomparable quality and is designed for exceptional performance, meeting the diverse needs of modern pressure measurement applications. We guarantee easy installation, precise output, robust build quality, resistance to harsh environments, and long operational life-features that make our transmitters a preferred choice compared to other products in the market. Take advantage of our limited stock and superb new offerings with supply ability available across All India. Experience unmatched reliability and seamless integration for your critical processes, and choose our Pressure Transmitters to benefit from the ultimate in technology and support.

TFP40C Ceramic Pressure Transmitter

Price 3500 INR/ Piece

MOQ : 5 Pieces

  • Accuracy
  • 0.5%FS (Typ.)
  • Compensated Temperature
  • -10C to 70C
  • Operating Temperature
  • -30C to 85C
  • Operating Voltage
  • 9-32V DC
  • Output
  • Other, 4-20mA, 0-10V, 0.5-4.5V
  • Output Voltage
  • 0.5 - 4.5V DC (typical)
  • Resistance
  • 100M @ 50V DC
  • Storage Temperature
  • -40C to 100C
  • Theory
  • Other, Piezo-resistive
  • Type
  • Ceramic Pressure Transmitter

TFP40S Piezoresistive Pressure Transmitter

Price 3500 INR/ Piece

MOQ : 5 Pieces

  • Accuracy
  • 0.25%FS, 0.5%FS, 1.0%FS (optional)
  • Compensated Temperature
  • -10C to +70C
  • Operating Temperature
  • -40C to +85C
  • Operating Voltage
  • 12-36V DC (current); 5V/12-36V DC (voltage)
  • Output
  • Other, 4-20mA, 0-10V, 0.5-4.5V, 0-5V (optional)
  • Output Voltage
  • 0-10V / 0.5-4.5V / 0-5V (optional)
  • Resistance
  • 100 M @ 50VDC
  • Storage Temperature
  • -40C to +125C
  • Theory
  • Other, Piezoresistive
  • Type
  • Piezoresistive Pressure Transmitter

TFP310 Flush Diaphragm Pressure Transmitter

Price 9500 INR/ Piece

MOQ : 5 Pieces

  • Accuracy
  • 0.5% F.S.
  • Compensated Temperature
  • +0C to +70C
  • Operating Temperature
  • -20C to +80C
  • Operating Voltage
  • 12-36V DC
  • Output
  • Other, 4-20mA, 0-10V, 0-5V (varies by model)
  • Output Voltage
  • 0-5V/0-10V (model specific)
  • Resistance
  • Insulation > 100M @ 100V DC
  • Storage Temperature
  • -40C to +125C
  • Theory
  • Other, Piezoresistive
  • Type
  • Flush Diaphragm Pressure Transmitter

TFPS70 Smart Pressure Transmitter

Price 38000 INR/ Piece

MOQ : 5 Pieces

  • Accuracy
  • 0.1% FS
  • Compensated Temperature
  • -10C to 70C
  • Operating Temperature
  • -40C to 85C
  • Operating Voltage
  • 10.5 V to 55 V DC
  • Output
  • Other, 4-20 mA, HART Protocol
  • Output Voltage
  • 10.5 V to 55 V DC
  • Resistance
  • 250 (minimum load for HART communication)
  • Storage Temperature
  • -40C to 125C
  • Theory
  • Other, Pressure Sensor
  • Type
  • Smart Pressure Transmitter

TFDP70 Smart Differential Pressure Transmitter

Price 44000 INR/ Piece

MOQ : 5 Pieces

  • Accuracy
  • +/-0.075
  • Compensated Temperature
  • -10C to 60C
  • Operating Temperature
  • -20C to 70C
  • Operating Voltage
  • 12 V DC
  • Output
  • Other, 4-20 mA
  • Resistance
  • Max 600
  • Storage Temperature
  • -40C to 85C
  • Theory
  • Other, Pressure Measurement
  • Type
  • Differential Pressure Transmitter

TFP40T Piezoresistive Pressure Transmitter

Price 12500 INR/ Piece

MOQ : 5 Pieces

  • Accuracy
  • 0.25%FS, 0.5%FS
  • Compensated Temperature
  • -20C ~ +85C
  • Operating Temperature
  • -40C ~ +85C
  • Operating Voltage
  • 12~36V DC
  • Output
  • Other, 4~20mA, 0~5V, 0~10V, RS485
  • Output Voltage
  • 0~5V, 0~10V
  • Resistance
  • Insulation Resistance 200M/250VDC
  • Storage Temperature
  • -40C ~ +125C
  • Theory
  • Other, Piezoresistive
  • Type
  • Piezoresistive Pressure Transmitter

TFP300 Flush Diaphragm Pressure Transmitter

MOQ : 5 Pieces

  • Accuracy
  • 0.5%FS, 0.25%FS, 0.1%FS (optional)
  • Compensated Temperature
  • -10C to 70C
  • Operating Temperature
  • -20C to 85C
  • Operating Voltage
  • 12~36V DC (for 4-20mA), 5V/12-30V DC (for voltage output)
  • Output
  • Other, 4-20 mA, 0-5V, 0-10V, RS485
  • Output Voltage
  • 0-5V/0-10V (optional)
  • Resistance
  • Zero Temperature Drift 0.02 %FS/C; Span Temperature Drift 0.02 %FS/C
  • Storage Temperature
  • -40C to 125C
  • Theory
  • Other, Piezoresistive Pressure Sensor
  • Type
  • Flush Diaphragm Pressure Transmitter
